Good Quality Leather Logo Hydraulic Leather Embossing Machine Embossing Machine For Leather
Technical parameters:
| Mechanical pressure | 30KN |
| Temperature regulation | 10~380°C |
| Temperature accuracy | ±2℃ |
| Drive way | hydraulic |
| Leather conveying mode | servo motor |
| Transmission accuracy | ±0.2MM |
| biggest pressure | 7Mpa |
| power supply | AC380V±5% 50/60HZ |
| Power: | 5KW |
| Cutting direction adjustment | up, down, left, right four directions |
| Hot press direction adjustment | left and right direction |
| Receiving bronzing paper | Automatic |
| Mode of operation | / Inching/automatic |
| Hot pressing time | 0.1S~999S |
| cutting time | 0.1S~999S |
| Way to work | / Manual/automatic |
| Mechanical pressure | 1T -3T |
| Heating plate area | 90×120MM |
| host volume | 1150×1160×1900MM |
| Upper and lower mold distance | 100MM |
| weight | 450KG |
1,Automatic constant temperature,
2,Automatic stop for lack of material
3,Quantity control automatic shutdown
4,Automatic counting
5,Four column structure
6,PLC+ touch screen
7,Automatic constant temperature
Name: Regulator
Brand:Independent research and development
Original: CHINA
Independent research and development, can X axis Y axis adjustment, machine cutting precision
Our products are sold all over the world, you can rest assured.
