Gluing Silicone Label Dispensing Shoe Sloe Vamp Slipper Making Machine For Sales

Gluing Silicone Label Dispensing Shoe Sloe Vamp Slipper Making Machine For Sales

  • NAME
    Dispensing Machine
  • Automatic Grade
    Full Automatic
  • Core Components
    PLC, Pressure Vessel, Other
  • Dimension(L*W*H)
    1250*1050*1560mm
  • Product Name
    24 Color Drop Molding Machine
  • Application
    Production Of PVC And Silica Gel Products
  • Mould Life
    100k- 500k Shots
  • Voltage
    220V
  • Weight
    420
  • Power (kW)
    1.6
  • Surface Treatment
    Texture
  • Keyword
    Plastic Injection Mold Molding Services
  • Keyword 1
    Automatic Phone Case Keychain Maker Machine
  • Keyword 2
    Rubber Shoes Sole Making Machine
  • Keyword 3
    Pvc Patch Making Machine
  • Place of Origin
    CHINA
  • Brand Name
    Fulund
  • Certification
    CE
  • Model Number
    FLD-24C
  • Minimum Order Quantity
    1
  • Price
    USD
  • Packaging Details
    WOODEN CASE
  • Delivery Time
    7days
  • Payment Terms
    T/T, Western Union, MoneyGram
  • Supply Ability
    100PCS/MONTH

Gluing Silicone Label Dispensing Shoe Sloe Vamp Slipper Making Machine For Sales

Gluing Silicone Label Dispensing Shoe Sloe Vamp Slipper Making Machine For Sales

How the glue dispenser works:
1. Working principle: Compressed air is fed into the rubber bottle (syringe), and the glue is pressed into the feed pipe connected to the piston chamber. When the piston is in the upper stroke, the piston chamber is filled with glue, and when the piston pushes down the glue When the needle is inserted, the glue is pressed out of the needle nozzle. The amount of glue dripped is determined by the distance of the plunger, which can be adjusted manually or automatically controlled in the software.
2. Features: high speed, low sensitivity to adhesive viscosity.
3. Advantages: It can improve the dispensing speed, improve the dispensing environment, and improve the dispensing quality.

Application Rang: PVC/Silicon logo, Trademark for garment, footwear outsole/Strap/Vamp, Shoe welting, Cup pad, Silicon keyboard cover, Non-slip mat, Refrigerator Sticker, Disney soft toy, Silicon Key Chain, PVC Zipper puller etc....



Technical parameters:

Model No. FLD-24C
Machine Size 1250*1050*1560mm
Weight 420KG
Electric Heating Power 1.6KW
Effective Trip 850*480*80mm
Worktable Size 890*460mm
