Direct Factory Price Hot Machine Rubber Stamp Vulcanizing Press For Motorcycle Tyre

Direct Factory Price Hot Machine Rubber Stamp Vulcanizing Press For Motorcycle Tyre

  • Machine Type
    Plate Vulcanizing Press, Vulcanizing Press
  • Dimension(L*W*H)
    1600*1200*1600MM
  • Operating Type
    Automatic
  • Voltage
    380V
  • Weight
    1100kg
  • Keyword 1
    Vulcanized Rubber Pressing Machine
  • Keyword 2
    Vulcanization Molding Curing Press Machine
  • Keyword 3
    Rubber Shoe Sole Vulcanizing Press
  • Place of Origin
    CHINA
  • Brand Name
    Fulund
  • Certification
    CE
  • Model Number
    FLD-V70T
  • Minimum Order Quantity
    1
  • Price
    USD
  • Packaging Details
    WOODEN CASE
  • Delivery Time
    7days
  • Payment Terms
    T/T, Western Union, MoneyGram
  • Supply Ability
    100PCS/MONTH

Direct Factory Price Hot Machine Rubber Stamp Vulcanizing Press For Motorcycle Tyre

Direct Factory Price Hot Machine Rubber Stamp Vulcanizing Press For Motorcycle Tyre

Vulcanizing Machine Troubleshooting
Since the vulcanizer is made of metal with high hardness, it is subjected to vibration shock and other compound forces during the production and operation process, resulting in the formation of gaps in the components and causing wear. The traditional repair methods include surfacing, thermal spraying, electric brushing, etc., but several methods have certain drawbacks: surfacing will make the surface of the part reach a high temperature, causing deformation or cracking of the part, affecting dimensional accuracy and normal use, In severe cases, it will lead to fracture; although the brush crossover has no thermal influence, the thickness of the crossover layer should not be too thick, the pollution is serious, and the application is also greatly limited. Western countries use polymer composite materials to solve the above problems. It has comprehensive performance and can be machined at any time, which can meet the use requirements and precision after repair, and can also reduce the impact and vibration of the equipment during operation and prolong its service life. Because the material is a "variable" relationship, when the external force impacts the material, the material will deform to absorb the external force, and expand and contract with the expansion and contraction of the bearing or other components, and always maintain a tight fit with the components to reduce the probability of wear. For the wear of large vulcanizers, "molds" or "matching parts" can also be used to repair damaged equipment on site, to avoid the overall disassembly of the equipment, to maximize the matching size of the parts, and to meet the production and operation requirements of the equipment.



Introduction to the structure of the vulcanizer:

1. Structural stability: a special four-column structure is adopted, the upper seat is reinforced with medium carbon steel, and the upright column is thickened and hardened to ensure structural stability and accuracy.

2. System: The high plane pressure equalization correction is adopted, and the pressure (18mpa) strengthens the nut leveling device, which can increase the parallelism of the upper and lower heating plates to 0.05mm.

3. Temperature control system: Adjustable from room temperature to 350°C, using intelligent temperature control to control the temperature fluctuation range within ±2°C.

4. Operating system: PLC combined with touch screen, whether debugging or production, can be controlled directly and simply.

5. Operating system: The optimally designed oil circuit and high-quality oil circuit accessories ensure the smooth operation of the entire oil circuit system from the principle and accessories.

6. Energy-saving system: The heating plate adopts the deep hole processing technology, which is closely matched with the heating pipe to reduce the heat loss during the heat transfer process.

7. The intelligent system can automatically push out the mold, thereby reducing the labor time of the staff, increasing efficiency, high output and saving time.



Scope of application:

Children's toys, baby products, kitchen supplies, clothing labels, equipment seals, etc.

Technical parameters:



Model No. FLD-V70T
Machine size 1600*1200*1600mm
Weight 1100kg
Power 13kw
Hot plate specifications 400*400mm
Temperature range Normal temperature -350℃
Hot plate spacing 200mm
Way to heat up Imported heating tube
Mold opening method Automatic mold release
System pressure 18MPa
Main column diameter 210mm
Clamping stroke 220mm
Work level Upper and lower layers
Motor power 3.75kw
Greatest pressure 70 tons
Machine structure Four-column/single-head model
Power specifications 380V/50HZ
